Tolleranze Dimensionali per Accoppiamenti Meccanici
ALBERO/FORO
UNI ISO 286-2 (ex UNI 6388 ISO R.286)
U11
U11
mm 100 ÷ 120=-0,144/-0,364
mm 120 ÷ 140=-0,170/-0,420
mm 140 ÷ 160=-0,190/-0,440
mm 160 ÷ 180=-0,210/-0,460
mm 180 ÷ 200=-0,236/-0,526
mm 200 ÷ 225=-0,258/-0,548
mm 225 ÷ 250=-0,284/-0,574
mm 250 ÷ 280=-0,315/-0,635
mm 280 ÷ 315=-0,350/-0,670
mm 315 ÷ 355=-0,390/-0,750
mm 355 ÷ 400=-0,435/-0,795
mm 400 ÷ 450=-0,490/-0,890
mm 450 ÷ 500=-0,540/-0,940
